DSP digital front stage DSP5.1

Model: DSP5.1 functional features
Music 1. Music parametric equalizer: 7 paragraph 2. The music to the main output high-pass filter: 12 db / 24 db (0 hz - 303 hz)
Mike 1. There are four microphone FBE mode: OFF 1 2 3 2. Mike wind pressure limit function 3. 15 balanced microphone parameters

  • details
  • attribute
Model: DSP5.1 functional features
Music 1. Music parametric equalizer: 7 paragraph 2. The music to the main output high-pass filter: 12 db / 24 db (0 hz - 303 hz)
Mike 1. There are four microphone FBE mode: OFF 1 2 3 2. Mike wind pressure limit function 3. 15 balanced microphone parameters
The effect
Echo: 1. Low pass filter of the echo: 5.99 Hz to 20.6 KHz 2. Echo high-pass filter: 0 Hz - 1000 Hz
3. The echo parametric equalizer: 3 paragraph 4. Echo level: 0 ~ 100% 5. Direct sound level of the echo: 0 ~ 100%
6. The echo time delay in advance: 0 ~ 500 ms 7. Echo right channel estimate time delay: 0 ~ + / - 50%, (relative left sound channel)
8. The echo delay in advance: 0 ~ 500 ms 9. Echo right channel delay: 0 ~ 50%, (relative left track the echo time delay time) 10. Echo repeat: 0 ~ 90%
Reverberation 1. Adjustable reverberation low-pass filter range: 5.99 Hz to 20.6 KHz 2. Adjustable reverberation high-pass filter range: 0 Hz - 1000 Hz 3. Adjustable reverberation level range: 0 ~ 100% 4. Adjustable reverberation direct sound range: 0 ~ 100%
5. In advance of the echo time delay adjustable range: 0 ~ 200 ms 6. Adjustable reverberation time range: 0 ~ 3000 ms
The main output (working mode: sing/dance (automatic/manual), contains in addition to the pressure limit, delay, mute all parameters)
1. The music level: 0 ~ 200%
2. The direct sound level: 0 ~ 200%
3. The level of the echo: 0 ~ 200%
4. The reverberation level: 0 ~ 200%
5. 5 section of the music parameters equilibrium
6. Compression limiting device
7. The left channel delay: 0 ~ 50 ms
8. The right channel delay: 0 ~ 50 ms
9. The left channel mute function
10. The right channel mute function
Output of (working mode: sing/dance (automatic/manual), contains in addition to the pressure limit, delay, mute all parameters)
1. The music level: 0 ~ 200%
2. The direct sound level: 0 ~ 200%
3. The level of the echo: 0 ~ 200%
4. The reverberation level: 0 ~ 200%
5. The high-pass filter: 0 hz - 303 hz
6. 3 period of parametric eq
7. Compression limiting device
8. The delay: 0 ~ 50 ms
9. Mute function
Subwoofer output (working mode: sing/dance with (automatic/manual), contains in addition to the pressure limit, delay, mute all parameters)
1. The music level: 0 ~ 400%
2. The MIC direct sound level: 0 ~ 200%
3. High-pass filter: 12 db, Q 0.4 ~ 1.5, 24 db / / Bessel Butterworth 24 db/Link Riley, 24 db/USER 12 db/USER 24 db (0 hz - 303 hz)
4. Low pass filter: 12 db, Q 0.4 ~ 1.5, 24 db/Link/Bessel 24 db/Butterworth Riley, 24 db/USER 12 db/USER 24 db (0 hz - 303 hz)
5. 3 period of parametric eq
6. Compression limiting device
7. The delay: 0 ~ 50 ms
